Features & Technical Specifications
FleetCore is a patented integrated safety signaling system designed for mobile fleet applications requiring continuous visibility, configurable signaling, and battery-isolated operation.
Battery Isolation and Internal Power
FleetCore is designed to prevent signaling loads from draining the vehicle battery while parked. Internal power support maintains visibility when equipment is off, with automatic recharge during operation.
Key Features
– Eliminates strobe-induced battery drain by design
– Supports parked vehicle visibility
– Reduces no-start events linked to signaling power draw
– Up to 2 weeks operation at maximum brightness
– Up to 4 weeks operation at reduced brightness
Configurable Fleet Signaling
FleetCore is highly configurable for fleet, site, and operating requirements. Multi-colour and pattern control allows the same integrated system to support different signaling standards across mine sites and equipment types.
Key Features
– Multi-colour signaling capability
– Configurable patterns and operating states
= Bluetooth and USB configuration
– Controlled access for setup
Designed for site-specific fleet requirements
System Consolidation
FleetCore consolidates multiple discrete lights, wiring runs, switches, and failure points into one integrated unit. This simplifies installation, reduces exposed components, and supports fleet standardization.
Key Features
– Single integrated unit replacing multiple lights
– Reduced wiring complexity
12 to 48 VDC compatible
– Intrinsic safe and non-intrinsic safe options
– Designed for mobile fleet environments
Autonomous Operation
FleetCore reduces reliance on manual operator action by supporting automatic signaling behaviour linked to vehicle state and site configuration.
Durability
FleetCore is engineered for harsh mining and industrial environments using polycarbonate and stainless steel construction. The sealed design supports protection against dust, debris, vibration, impact, and moisture.
Key Features
– Maintains correct signaling
Reduces operator dependence
– Supports compliance workflows
– Improves fleet visibility consistency
Key Features
– Polycarbonate and stainless steel construction
– Sealed against dust, debris, and moisture
– Designed for vibration and impact exposure
– Suitable for mining and industrial use
LIGHTING SPECIFICATIONS
CLEAR LIGHTS
CLEAR LIGHTS activate automatically when the vehicle’s master switch is OFF and de-activates when the vehicle’s master switch is ON.
BLUE LIGHTS
BLUE LIGHTS activate automatically when the vehicle’s master switch is ON (clear strobe will automatically de-activate in this case and internal battery begins to charge.)
RED LIGHTS
RED LIGHTS activate automatically when switch is ON, with vehicle’s master switch ON or OFF.
AMBER LIGHTS
AMBER LIGHTS activate automatically when switch is ON, with vehicle’s master switch ON or OFF.
